X7 GLASS Dual Desfire terminal

POE Multifunction Terminal with Gate Management and Large 7" Display

Suitable for all types of work environments, including outdoor

Perfect for displaying badges, messages to users, images, or a lot of data thanks to the large display and customizable screens.

• Orientation: horizontal or vertical
• RF5 Multi-technology Reader

X7 and X7 Glass, with the new RF5 reader, can read cards:

• 125 KHZ EM4102 and compatible
• 13.56 MHz Mifare: Ultralight, Classic 1K, 4K, Classic EV1 1K, DESFIRE
• 14443A
• NFC Forum Type2 tags
• Antenna: single or dual
• WEB Interface

  The terminals are fully configurable and manageable via the web (configuration parameters, cards, users by name, permissions, timestamp review, gate configuration, etc.).

• Ready to use

All attendance detection and access control functions are already integrated and configurable even from the web (time bands, reasons, sirens, PIN access, white list, etc.).

• Memory

Internal uSD (industrial, 4 GB) included. Stores configurations, users (over 100,000), and timestamps (over 1M). Replacement recommended every 3 years.

• Complete management of independent gates (up to 8 doors)

The terminals can fully manage a multi-gate access control system thanks to the wide range of optional devices they can control.

• Up to 3 connectable readers - one internally integrated reader and 2 external readers
