Smart Mobile Terminal SUNMI V3 MIX

SUNMI V3 MIX Smart Mobile Terminal

MIX, the all-in-one entreprise tablet

MIX your POS terminal to capture businesses anywhere, anytime

10” high-resolution display and a built-in high speed printer make a mobile and desktop terminal.

MIX, design not only for payment

Ergonomically designed for a comfortable grip. Professional scanner integrated 1D/2D barcode scanning. Aluminum-magnesium alloy frame and incell touchscreen make it strong yet slim and light.

MIX for higher performance

Qualcomm hexa-core processor and 4GB RAM+32GB ROM for an assured strong performance.

MIX for wider extensibility

Specially designed rotatable functional cradle enable cash drawer, handheld scanner and network among other accessories that boost your business.

---

SUNMI V3 MIX Application Scenario

• Tableside Ordering
• One-in-one Service
• Drive ThruNFC reader
• Inventory Check

---

SUNMI V3 MIX Tech Specs

General Configuration

• Product Model: T5701 58mm version
  T5711 80mm version
• OS: SUNMI OS 4.0 (based on Android 13)
• Processor: Qualcomm hexa-core, 2.4GHz /2.0GHz
• Memory: 4GB RAM+32GB ROM
• Display: 10.1'' HD 1280*800 IPS
• Battery: Removable Lithium battery 7.2V/2600mAh
• Camera: Front: 2MP FF
  QR Payment 0.3 MP FF
• Scanner: 2D professional scanner
• Wi-Fi: Supports IEEE 802.11 a/b/g/n/ac 2.4G/5G
• Speaker: 12W
• Bluetooth: BT2.1/3.0/4.2, BLE supported
• Button: Power key button  Volume Key  and Scan Key
• GPS: GPS, AGPS
• NFC Reader: Type A&B card
  Mifare card, FeLica card
  ISO/IEC 14443
  and ISO 15693 compliant
• Dimensions: 246*231*73mm
• Weight: 670g (58mm)/710g (80mm)
• Cradle (Optional): For charging,   3*USB Type A,   RJ11,   RJ45 
• Cradle Customer Display (Optional): USB  6.7'' touchscreen
• Environment: Operating temperature: 0°C – 45)C (except 3D camera)
  Storage temperature: -20°C – 60°C

---

	58mm version	80mm version
Printer	Thermal Printer, Print speed: 70mm/s Paper Roll Width / Diameter: 58mm / 40mm	Thermal Printer, Print speed: 70mm/s Paper Roll Width / Diameter: 80mm / 40mm
